Fuel Oil Delivery 250 PSI Hose
Applications & Features
Designed to transfer fuel oils, diesel, or commercial gasolines. Compatible with bio-diesel fuels up to B20.
Specs
Tube:
Nitrile RMA Class A
Cover:
Nitrile RMA Class A/PVC blend
Reinforcement:
Four textile spirals
Safety Factor:
4:1 Burst pressure to working pressure
Temp. Range:
-40°F to 212°F
Gasoline normall transferred below 120°F
| Part # | ID | OD/Tolerance | Max WP | Bend Radius | Weight | Length |
|---|---|---|---|---|---|---|
| INCH | INCH | PSI | INCH | LBS/FT | FEET | |
| FUELDEL250-12 | 3/4 | 1.26 | 250 | 6.10 | 0.59 | 100/125/150/175 |
| FUELDEL250-16 | 1 | 1.50 | 250 | 7.00 | 0.47 | 100/125/150/175 |
| FUELDEL250-20 | 1-1/4 | 1.78 | 250 | 8.75 | 0.59 | 100/125/150/175 |
| FUELDEL250-24 | 1-1/2 | 1.88 | 250 | 9.25 | 0.65 | 100/125/150/175 |
