Pressure Washer 3K 4K 6K
Applications & Features
Single or double wire braids, synthetic rubber tube, abrasion and ozone resistant synthetic rubber cover.
Specs
Tube:
Synthetic rubber
Cover:
Synthetic rubber
Reinforcement:
One high tensile steel wire braid
Temp. Range:
0°F to 200°F pressure washer service
-40°F to 250°F hydraulic service
Colors:
Blue, Black, Grey
| Part # | ID | OD/Tolerance | Max WP | Min BP | Bend Radius | Weight | Fitting Series | Length |
|---|---|---|---|---|---|---|---|---|
| INCH | INCH | PSI | PSI | INCH | LBS/FT | FEET | ||
| MWHPWBU-04 | 1/4 | 0.520 +/- .020 | 3,000 | 12,000 | 3.9 | 0.15 | 2WB | 500 |
| MWHPWBU-06 | 3/8 | 0.677 +/- .020 | 3,000 | 12,000 | 5.1 | 0.22 | 2WB | 400 |
| MWHPWBU-08 | 1/2 | 0.813 +/- .030 | 3,000 | 12,000 | 7.1 | 0.27 | 2WB | 300 |
